Spring Boot: Creation,Dépendances et Configuration

Architecture d'une Application Spring Boot

Client
- Représente l'application frontale (web ou mobile) qui envoie des requêtes HTTP.
API Gateway
- Point d'entrée pour toutes les requêtes des clients. Il redirige les requêtes vers les services appropriés.
Spring Boot Application
- Le cœur de l'application contenant la logique métier, comprenant :
  - Controllers : Gèrent les requêtes entrantes et les réponses.
  - Services : Contiennent la logique métier et interagissent avec les Repositories .
  - Repositories : Gèrent l'accès aux données et les interactions avec la base de données.
Database
- Solution de stockage persistant pour les données de l'application (ex. : MySQL, PostgreSQL).
Microservices
- Services indépendants offrant des fonctionnalités spécifiques, pouvant être développés et déployés séparément.
Auth Server
- Responsable de l'authentification et de l'autorisation, génère et valide les jetons d'accès.
Cache
- Mécanisme de stockage des données fréquemment consultées en mémoire, améliorant les performances.
Message Broker
- Facilite la communication asynchrone entre les composants ou microservices (ex. : RabbitMQ, Kafka).
Database Queries
- Interactions entre l'application Spring Boot et la base de données pour les opérations CRUD.

Résumé

L'architecture est conçue pour favoriser la séparation des préoccupations, permettant une maintenance, une évolutivité et une flexibilité plus faciles dans le développement et le déploiement d'applications. Chaque composant interagit avec les autres pour offrir une expérience fluide à l'utilisateur final tout en assurant des opérations sécurisées, efficaces et fiables.

Implementing: Client → Gateway → Spring Boot App → Microservices, Cache, DB, Auth Server

Note: This tutorial implements the architecture shown in your diagram: Client → API Gateway → Spring Boot Application → Microservices, Cache, Database, Auth Server. We'll use Spring Boot, Spring Data JPA, Spring Cache, Spring Security, and Spring Cloud Gateway.

📁 Project Structure

api-gateway — Routes requests
spring-boot-app — Main application (calls microservices, cache, DB, auth)
microservice-a — Example microservice
cache-server — Redis (optional)
database — H2 or MySQL
auth-server — OAuth2 server

Step 1: Create API Gateway

📁 File: `api-gateway/pom.xml`

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>3.2.5</version>
        <relativePath/>
    </parent>

    <groupId>com.bbank</groupId>
    <artifactId>api-gateway</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <name>api-gateway</name>

    <properties>
        <java.version>17</java.version>
        <spring-cloud.version>2023.0.1</spring-cloud.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-gateway</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-netflix-eureka-client</artifactId>
        </dependency>
    </dependencies>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>${spring-cloud.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>
</project>

📁 File: `api-gateway/src/main/resources/application.yml`

server:
  port: 8080

spring:
  application:
    name: api-gateway
  cloud:
    gateway:
      routes:
        - id: spring-boot-app
          uri: lb://spring-boot-app
          predicates:
            - Path=/api/**
        - id: microservice-a
          uri: lb://microservice-a
          predicates:
            - Path=/msa/**

eureka:
  client:
    service-url:
      defaultZone: http://localhost:8761/eureka

📁 File: `api-gateway/src/main/java/com/bbank/apigateway/ApiGatewayApplication.java`

package com.bbank.apigateway;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;

@SpringBootApplication
@EnableDiscoveryClient
public class ApiGatewayApplication {
    public static void main(String[] args) {
        SpringApplication.run(ApiGatewayApplication.class, args);
    }
}

Step 2: Create Spring Boot Application

📁 File: `spring-boot-app/pom.xml`

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>3.2.5</version>
        <relativePath/>
    </parent>

    <groupId>com.bbank</groupId>
    <artifactId>spring-boot-app</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <name>spring-boot-app</name>

    <properties>
        <java.version>17</java.version>
        <spring-cloud.version>2023.0.1</spring-cloud.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-cache</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-security</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-openfeign</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-netflix-eureka-client</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-validation</artifactId>
        </dependency>
        <dependency>
            <groupId>com.h2database</groupId>
            <artifactId>h2</artifactId>
            <scope>runtime</scope>
        </dependency>
    </dependencies>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>${spring-cloud.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>
</project>

📁 File: `spring-boot-app/src/main/resources/application.yml`

server:
  port: 8081

spring:
  application:
    name: spring-boot-app
  datasource:
    url: jdbc:h2:mem:bbank-db
    driver-class-name: org.h2.Driver
    username: sa
    password:
  jpa:
    hibernate:
      ddl-auto: update
    show-sql: true
  cache:
    type: simple
  feign:
    client:
      config:
        default:
          connectTimeout: 5000
          readTimeout: 5000
  security:
    oauth2:
      resourceserver:
        jwt:
          issuer-uri: http://localhost:9000/oauth2/token

eureka:
  client:
    service-url:
      defaultZone: http://localhost:8761/eureka

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/model/User.java`

package com.bbank.springbootapp.model;

import jakarta.persistence.*;

@Entity
@Table(name = "users")
public class User {
    @Id
    @GeneratedValue(strategy = GenerationType.IDENTITY)
    private Long id;
    private String name;
    private String email;

    // Constructors
    public User() {}
    public User(String name, String email) {
        this.name = name;
        this.email = email;
    }

    // Getters and Setters
    public Long getId() { return id; }
    public void setId(Long id) { this.id = id; }
    public String getName() { return name; }
    public void setName(String name) { this.name = name; }
    public String getEmail() { return email; }
    public void setEmail(String email) { this.email = email; }
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/repository/UserRepository.java`

package com.bbank.springbootapp.repository;

import com.bbank.springbootapp.model.User;
import org.springframework.data.jpa.repository.JpaRepository;

public interface UserRepository extends JpaRepository<User, Long> {
    User findByEmail(String email);
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/service/UserService.java`

package com.bbank.springbootapp.service;

import com.bbank.springbootapp.model.User;
import com.bbank.springbootapp.repository.UserRepository;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.cache.annotation.Cacheable;
import org.springframework.stereotype.Service;

@Service
public class UserService {

    @Autowired
    private UserRepository userRepository;

    @Cacheable(value = "users", key = "#email")
    public User getUserByEmail(String email) {
        return userRepository.findByEmail(email);
    }

    public User saveUser(User user) {
        return userRepository.save(user);
    }
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/controller/UserController.java`

package com.bbank.springbootapp.controller;

import com.bbank.springbootapp.model.User;
import com.bbank.springbootapp.service.UserService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.*;

@RestController
@RequestMapping("/api/users")
public class UserController {

    @Autowired
    private UserService userService;

    @GetMapping("/{email}")
    public User getUser(@PathVariable String email) {
        return userService.getUserByEmail(email);
    }

    @PostMapping
    public User createUser(@RequestBody User user) {
        return userService.saveUser(user);
    }
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/config/SecurityConfig.java`

package com.bbank.springbootapp.config;

import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.config.annotation.web.configuration.EnableWebSecurity;
import org.springframework.security.config.http.SessionCreationPolicy;
import org.springframework.security.oauth2.server.resource.authentication.JwtAuthenticationConverter;
import org.springframework.security.oauth2.server.resource.authentication.JwtGrantedAuthoritiesConverter;
import org.springframework.security.web.SecurityFilterChain;

@Configuration
@EnableWebSecurity
public class SecurityConfig {

    @Bean
    public SecurityFilterChain filterChain(HttpSecurity http) throws Exception {
        http
            .csrf().disable()
            .sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS)
            .and()
            .authorizeHttpRequests(authz -> authz
                .requestMatchers("/api/users/**").authenticated()
                .anyRequest().permitAll()
            )
            .oauth2ResourceServer(oauth2 -> oauth2
                .jwt(jwt -> jwt
                    .jwtAuthenticationConverter(jwtAuthenticationConverter())
                )
            );
        return http.build();
    }

    @Bean
    public JwtAuthenticationConverter jwtAuthenticationConverter() {
        JwtGrantedAuthoritiesConverter grantedAuthoritiesConverter = new JwtGrantedAuthoritiesConverter();
        grantedAuthoritiesConverter.setAuthorityPrefix("ROLE_");
        JwtAuthenticationConverter converter = new JwtAuthenticationConverter();
        converter.setJwtGrantedAuthoritiesConverter(grantedAuthoritiesConverter);
        return converter;
    }
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/client/MicroserviceAClient.java`

package com.bbank.springbootapp.client;

import org.springframework.cloud.openfeign.FeignClient;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PathVariable;

@FeignClient(name = "microservice-a")
public interface MicroserviceAClient {

    @GetMapping("/msa/data/{id}")
    String getData(@PathVariable Long id);
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/service/MicroserviceAService.java`

package com.bbank.springbootapp.service;

import com.bbank.springbootapp.client.MicroserviceAClient;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

@Service
public class MicroserviceAService {

    @Autowired
    private MicroserviceAClient microserviceAClient;

    public String callMicroserviceA(Long id) {
        return microserviceAClient.getData(id);
    }
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/controller/IntegrationController.java`

package com.bbank.springbootapp.controller;

import com.bbank.springbootapp.service.MicroserviceAService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RestController;

@RestController
@RequestMapping("/api/integration")
public class IntegrationController {

    @Autowired
    private MicroserviceAService microserviceAService;

    @GetMapping("/call-msa/{id}")
    public String callMicroserviceA(@PathVariable Long id) {
        return microserviceAService.callMicroserviceA(id);
    }
}

📁 File: `spring-boot-app/src/main/java/com/bbank/springbootapp/SpringBootApplication.java`

package com.bbank.springbootapp;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;

@SpringBootApplication
@EnableDiscoveryClient
public class SpringBootApplication {
    public static void main(String[] args) {
        SpringApplication.run(SpringBootApplication.class, args);
    }
}

Step 3: Create Microservice A

📁 File: `microservice-a/pom.xml`

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>3.2.5</version>
        <relativePath/>
    </parent>

    <groupId>com.bbank</groupId>
    <artifactId>microservice-a</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <name>microservice-a</name>

    <properties>
        <java.version>17</java.version>
        <spring-cloud.version>2023.0.1</spring-cloud.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-netflix-eureka-client</artifactId>
        </dependency>
    </dependencies>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>${spring-cloud.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>
</project>

📁 File: `microservice-a/src/main/resources/application.yml`

server:
  port: 8082

spring:
  application:
    name: microservice-a

eureka:
  client:
    service-url:
      defaultZone: http://localhost:8761/eureka

📁 File: `microservice-a/src/main/java/com/bbank/microservicea/MicroserviceAApplication.java`

package com.bbank.microservicea;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;

@SpringBootApplication
@EnableDiscoveryClient
public class MicroserviceAApplication {
    public static void main(String[] args) {
        SpringApplication.run(MicroserviceAApplication.class, args);
    }
}

📁 File: `microservice-a/src/main/java/com/bbank/microservicea/controller/DataController.java`

package com.bbank.microservicea.controller;

import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RestController;

@RestController
public class DataController {

    @GetMapping("/data/{id}")
    public String getData(@PathVariable Long id) {
        return "Data from Microservice A for ID: " + id;
    }
}

Step 4: Create Auth Server (OAuth2)

📁 File: `auth-server/pom.xml`

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>3.2.5</version>
        <relativePath/>
    </parent>

    <groupId>com.bbank</groupId>
    <artifactId>auth-server</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <name>auth-server</name>

    <properties>
        <java.version>17</java.version>
        <spring-cloud.version>2023.0.1</spring-cloud.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-oauth2-resource-server</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>
        <dependency>
            <groupId>com.h2database</groupId>
            <artifactId>h2</artifactId>
            <scope>runtime</scope>
        </dependency>
    </dependencies>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>${spring-cloud.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>
</project>

📁 File: `auth-server/src/main/resources/application.yml`

server:
  port: 9000

spring:
  application:
    name: auth-server
  datasource:
    url: jdbc:h2:mem:auth-db
    driver-class-name: org.h2.Driver
    username: sa
    password:
  jpa:
    hibernate:
      ddl-auto: update
    show-sql: true

security:
  oauth2:
    authorization-server:
      issue-token:
        access-token:
          value-creator: org.springframework.security.oauth2.server.authorization.token.DefaultAccessTokenValueCreator
      client:
        - client-id: myclient
          client-secret: mysecret
          scopes:
            - read
            - write
          authorities:
            - ROLE_USER
          redirect-uri: "http://localhost:8081/login"
          post-logout-redirect-uri: "http://localhost:8081/logout"
          grant-types:
            - authorization_code
            - refresh_token
            - client_credentials
          secret: mysecret
          token-settings:
            access-token-time-to-live: 3600
            refresh-token-time-to-live: 86400

📁 File: `auth-server/src/main/java/com/bbank/authserver/AuthServerApplication.java`

package com.bbank.authserver;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@SpringBootApplication
public class AuthServerApplication {
    public static void main(String[] args) {
        SpringApplication.run(AuthServerApplication.class, args);
    }
}

✅ Step 5: Run & Test

▶️ Start Order:

Start Eureka Server → http://localhost:8761
Start Auth Server → http://localhost:9000
Start Microservice A
Start Spring Boot App
Start API Gateway → http://localhost:8080

🧪 Test via Gateway:

curl -X POST http://localhost:8080/api/users \
  -H "Content-Type: application/json" \
  -d "{ \"name\": \"John Doe\", \"email\": \"john@example.com\" }"

curl -X GET http://localhost:8080/api/users/john@example.com \
  -H "Authorization: Bearer YOUR_TOKEN"

curl -X GET http://localhost:8080/api/integration/call-msa/123 \
  -H "Authorization: Bearer YOUR_TOKEN"

🎉 FULL ARCHITECTURE COMPLETE!
- Client → Gateway → Spring Boot App → Microservices, Cache, DB, Auth
- Caching with `@Cacheable`
- Database with JPA/H2
- Authentication with OAuth2
- Service calls via Feign

Les étapes à suivre

1Création d'un projet SpringBoot avec initializr
2Choix des dépendaces du fichier pom.xml
3Télécher puis importer le projet dans Eclipse
4Configuration du fichier properties.json
5Créer la base de données

1.Création d'un projet SpringBoot avec initializr

Spring Initializr est une application Web qui permet de générer la structure un projet Spring Boot et ajouter les dépendances du projet le site web de l'application: https://start.spring.io

2.Spring Initializr permet de choisir les dépendances qui seront utilisées dans le projet :

Spring Web

Créez des applications Web, y compris RESTful, à l'aide de Spring MVC. Utilise Apache Tomcat comme conteneur intégré par défaut.
Spring Data JPA

Conservez les données dans les base de données SQL avec l'API Java Persistence en utilisant Spring Data et Hibernate.
Driver MySQL

Pilote MySQL JDBC.
Spring Boot DevTools

Fournit des redémarrages rapides des applications, LiveReload et des configurations pour une expérience de développement améliorée.

3.Télécher puis importer le projet dans Eclipse

Une fois le projet est créer on doit le télécharger pour l'inporter dans eclipse

GENERATE

4.Télécher puis importer le projet dans Eclipse

Extraire le projet puis ouvrir eclipse ->File->import->maven Project->existing maven project->chosir ton projet ->next finish

5.Configuration du fichier properties.json

resources/properties.json est un fichier de configuration de projet permet de déclarer un ensembles de beans qui seront utilsés par Spring ioc pour instancer des objets lorsque on utilise l'annoation @Autowired exemples:

spring.jpa.hibernate.ddl-auto=create
spring.datasource.url=jdbc:mysql://localhost:3306/springbootDBs?serverTimezone=UTC
spring.datasource.username=root
spring.datasource.password=
server.port=8097
spring.jpa.database-platform = org.hibernate.dialect.MySQL5Dialect

Explications:

#activation de ddl data definition language

#create permet dropt table if exist and create table
#update permet d'appliquer les modification sur une table existe déja
spring.jpa.hibernate.ddl-auto=update
#la chaine de connexion à l base de données
spring.datasource.url=jdbc:mysql://localhost:3306/springbootDBs?serverTimezone=UTC
#uitlisateur de la base de données
spring.datasource.username=root
#password de l'utilisateur de la base de données
spring.datasource.password=
#le numero de port du projet
#http://localhost:8097
server.port=8097
#le type des requêtes sql qui seront générées dans ce cas mysql

6.Créer la base de données

dans le fichier de configuration properties.json on a met mysql://localhost:3306/springbootDB donc il faut créer la base de données

springbootDB dans MySQL

Rappel

Spring Boot (BackEnd) TPs

Produit Rest API

Angular (FrontEnd)

Spring Security

CRUD

To be Continued...

Middlewares Orientés Messages

Communication Synchrone vs. Asynchrone API JMS : Java Message Service JMS avec ActiveMQ et HornetQ KAFKA

Spring Batch

Spring Batch

Stream Processing

Kafka Streams

Architectures Serverless

Architectures Serverless Résumé

Architecture d'une Application Spring Boot

Résumé

Implementing: Client → Gateway → Spring Boot App → Microservices, Cache, DB, Auth Server

📁 Project Structure

Step 1: Create API Gateway

📁 File: api-gateway/pom.xml

📁 File: api-gateway/src/main/resources/application.yml

📁 File: api-gateway/src/main/java/com/bbank/apigateway/ApiGatewayApplication.java

Step 2: Create Spring Boot Application

📁 File: spring-boot-app/pom.xml

📁 File: spring-boot-app/src/main/resources/application.yml

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/model/User.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/repository/UserRepository.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/service/UserService.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/controller/UserController.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/config/SecurityConfig.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/client/MicroserviceAClient.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/service/MicroserviceAService.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/controller/IntegrationController.java

📁 File: spring-boot-app/src/main/java/com/bbank/springbootapp/SpringBootApplication.java
